Measurements:



LOA: 54 ft 6 in

Beam: 15 ft 1 in

Number of Heads: 2

Propulsion:


Engine #1

Engine Make: Volvo Penta

Engine Model: IPS 600

Primary Engines: Inboard

Drive Type: Pod Drive

Location: Port

Hours: 1500Power: 435 hp

Engine #2

Engine Make: Volvo Penta

Engine Model: IPS 600

Primary Engines: Inboard

Drive Type: Pod Drive

Location: Center

Hours: 1500

Power: 435 hp

Engine #3

Engine Make: Volvo Penta

Engine Model: IPS 600

Primary Engines: Inboard

Drive Type: Pod Drive

Location: Starboard

Hours: 1500

Power: 435 hp

Additional Specs, Equipment and Information:



"GOOMBAY" has undergone a major transformation over the last year or so.Her entire electrical system has been redone to the US Standards, including new circuit breaker banks and a Czone ships functionality control system.This was done by one of the most respected electrical contractors, SEAtec Marine.

She has had new, thicker, teak decks done in 2019.She was fully repainted in 2019.She has a newly installed water maker.The air conditioning system was fully redone with new compressor and air handlers.New helm electronics and galley equipment was also done at the same time.

She could be considered better than new!  She has very low engine and generator hours and is in Bristol condition, ready to go.

What makes the Carbon 54 so special is the panoramic views out of the salon and helm area.Nearly 360 degrees of unobstructed views!  The opening sun roof brings in plenty of sunshine andfresh air.

The layout on the main deck is an entertainers dream!  Plenty of comfortable seating for dining,lounging or even dancing on the aft deck and swim platform!  The galley has all that you need to prepare wonderful meals for your guests.

Down below, the guest cabins are extremely well laid out with ample space for moving about andplenty of storage.  The richness of the wood and fabrics exude quality and create an atmosphere of luxury unseen on yachts of this size.  The owner's cabin is very large, with an ensuite head and shower.

The Delta Powerboats Carbon 54 hull provides for a stable and enjoyable ride as the boat nearly rides on a cushion of air.  The downward chines of the hull guide air under the boat to help increase speed and soften the ride.



Vessel: 54 Carbon IPS #7, “Goombay”

LOA: 18.10 m | 59.4 ft.

Hull Length: 16.60 m | 54.5 ft.

Beam: 4.6 m | 15.1 ft.

Draft: 1.4 m | 4.6 ft.

Heights:

Displ: 30,800 # wet

Displ: 28,000 # dry

Total Displacement with fuel, water, guests etc....... 44,000 # total capacity

Fuel: 2,900 liters | 740 US gallons

Fresh Water: 700 liters | 185 US gallons

Black Water: 200 liters | 53 US gallons

Grey Water: 200 liters | 53 US gallons

Cruise Speed: 25-30 knots [Triple IPS]

Top Speed: 38-39 knots [Triple IPS]



DESIGN: CONSTRUCTION:

CE Classificattion: B

Designer: Lars Modin

Construction: Hull, Superstructure, Interior: Lightcraft/Diab/Luksujaht Electrical MasterVolt/Luksusjaht

Manufacturor: Luksusjaht AS

MATERIALS & TECHNOLOGY:

Air-supported deep v hull

Hull + Stringers in Vacuum Infusion Laminated carbon fiber | vinylester | divinycell

Bulkheads in Vacuum Infusion Laminated carbon fiber | vinylester | divinycell

Deck in Vacuum Infusion Laminated carbon fiber | vinylester | divinycell

Roof in Vacuum Infusion Laminated carbon fiber | vinylester | divinycell

2 Waterlines in white

Exterior paint new as of Feb 2019



DECK FITTINGS AND EQUIPMENT:

SS custom-made forward flagpole

SS custom-made flagpole

SS custom-made radar arch

2 x Carbon fiber fishing out riggers

Large forward locker + anchor locker + fender locker

SS custom-made bow roller + guard for anchorSS custom-made Bruce anchor

SS custom-made forward mooring cleats

SS custom-made amidships mooring cleats

SS custom-made aft mooring cleats

2 x Deck storage hatches on deck

5 x Deck storage in aft cockpit area

4 x SS fender attachments forward of handrail

1 x Lewmar skylight flush for Owner’s cabin

1 x Lewmar skylight, flush, for anchor box

1 x Lewmar hatch in Owner’s cabin

2 x Lewmar flush skylights toilet/bathrooms

1 x Webasto electric panoramic sunroof in salon

3 x Fwd Windscreens 12 mm laminated glass

6 x Side windows in 12 mm laminated glass

2 x SS grab rails along walk-around

1 x SS grabrail on roof

1 x SS custom-made aft sliding salon door [4 sections – 2 active, 2 inactive]

2 x SS aft pushpits

1 x hydraulic swim platform for tender/jet storage.

4 x SS custom-made engine vents

1 x Hand laid 10 mm solid teak deck replaced June 2019

12 x Outside LED-lights

7 x Fenders

Mooring lines

1 Set outside cushions1 set flybridge bunny pad cushions

1 Set forward sun pad cushions

4 x summit teak chairs1 x summit teak bench

1 x hydraulic table that retreats into deck

Outdoor speakers

POWERPLANTS AND CONTROLS:

3 x Volvo Penta IPS 600 435 HP each, 1305 HP total

Engine hours approx: 1,500

1 x Electronic steering by Volvo Penta

1 x Electronic helm by Volvo Penta

1 x IPS joystick by Volvo Penta mounted inside

1 x IPS joystick by Volvo Penta mounted outside

1 x 7” color LCD-display engine and systems monitoring

1 x Diesel flow meter/trip computer interface by Volvo Penta

4 x Fixed diesel

x Engine-room light

1 x Automatic fire extinguisher in engine room

1 x Automatic bilge pump 24 V.

1 x Hydraulic engine room hatch lift

1 x 110v outlet

1 x 12voutlet

1 x Pair Humphree interceptors with LCD-display and controls

ELECTRICAL:

In 2018/2019 the entire electrical system was redone to US standards. All systems and appliances were replaced with 60 Hz components. This included all galley appliances.24v electrical system from SeaTec Marine built with Czone syste. This system controls much ofthe ships system and can wirelessly be controlled by an IPhone or IPad.  In fact, the main control isa removable IPad.  The Czone functions can also be controlled through the Simrad displays at the helm.

Custom built 120/240 VAC Breaker panel designed by SeaTec Marine, built by Paneltronics

Custom built battery switch and control panel designed by SeaTec Marine/Electra and built by Ward’s Marine

There are six battery banks in total, each with a remote activated switch

1 House battery bank

3 Engine battery banks

1 Generator battery bank1 Stereo battery bank

Northern Lights Generator 20 KW 110V

4 x Electrical main switches with remote switching from salon controls station

1 x Czone Master Display, 10” LCD (IPad) with complete setup for monitoring yacht

2 x 50A shorepower cables with 50A pigtail adapter

2 x Charles 50A IsoBoost isolalation transformers, one for each power cord

Battery charger – Mastervolt Chargemaster 24/20-3

Battery charger – Mastervolt Chargemaster 12/50-3Battery charger – Dolphin Pro 24.40

LED navlights

SS horns

Full 110v 60hz system

TECHNICAL:

Cruiseair 45000 Btu

SeaKeeper M8000 Gyro

1 x Water Heater, 50l with heat exchange from engine or via 220v heater

2 x Eberspracher D5 heaters (salon area & sleeping area)

1 X Watermaker

1 x Jabsco automatic water pump with pressure tank

2 x 12v Jabsco bilgepumps

3 x Windscreen wipers

1 x Windscreen wash

6 x Bilge pumps

INSTRUMENTS:

SIMRAD VHF

SIMRAD Auto pilot

2 SIMRAD digital displays

2 SIMRAD GPS chart plotters

1 SIMRAD controller

1 SIMRAD radar

1 x Jabsco searchlight with fixed remote control

1 x Silva 100 compass

GALLEY:

Interior design in finest selected teak, 8 layers of varnish, Corian wall, kitchen-top in Corian andsolid teak flooring

1 x Siemens Cooktop, 110V, new 2019

1 x Siemens “Speed Oven” oven/micro combination, 110V new 2019

1 x Siemens dish washer, 110V, new 2019

1 x SS double sink

1 x Kitchen Faucet by Vola design/Arne Jacobsen

1 x SS Fridge drawers units, new 2019

1 Freezer unit under the floor in salon

1 x SS grab rail around kitchen.

1 x 110v outlet3 x LED spotlights

4 x Integrated glass-storages for 32 glasses

4 x Drawers

1 x Kitchen exhaust fan, 24v

1 x Bar

SALON:

Interior design in finest selected teak, 8 layers of varnish, removable panels covered in Italian fabrics, and solid teak floors

1 x Isotherm automatic icemaker

1 x Chest freezer/fridge below galley sole

1 x Double adjustable captain’s seats with Sunbrella fabrics

1 x Triple sofa with Sunbrella fabrics

1 x Foldable coffee table in teak

6 x Large sofa in salon with Sunbrella fabrics

8 x Oceanair curtains

1 x 40 in Samsung 4k TV which retracts into the cabin overhead, so fully out of sight

1 x Double movable ottoman

1 x Single ottoman

1 x Salon table in teak

8 x SS grabrails

2 x 12v outlets

3 x 110v outlets

2 x USB outlets for charging smartphones

1 x Bluetooth operated stereo with 4 hidden speakers and amp

1 x Defroster outlet w/ hot air

3 x Eberspraher heater outlets

12 x LED overhead lights

1 x Sliding side door for Captain

8 x Cup holders

4 x Storage drawers in various sizes

OWNER’S STATEROOM:

Interior design in finest selected teak, 8 layers of varnish, removable panels covered in Italian

2 x SS grab rails around wardrobes

2 x 12v outlets

1 x USB outlet charging outlet for smartphones

2 x 110v outlets

1 x CD stereo w/ 2 hidden speakers

2 x Heater outlets

10 x LED spotlights in ceiling2 x LED reading lights

4 x Concealed lights

2 x Removable chairs

4 x Storage

2 x Wardrobes

1 x Oceanair curtain in roof

2 x Oceanair curtains for side windows

1x Samsung 4k 40inch TV

GUEST STATEROOMS:

Interior design in finest selected teak, 8 layers of varnish, removable panels covered in Italian fabrics, and solid teak floors

2 x Luxury mattress’s per cabin

1 x 12 v outlet

1 x CD stereo with 2 hidden speakers

1 x USB outlet

1 x 110v outlets

1 x 25in Samsung TV

1 x Heater outlet

3 x LED spotlights

2 x LED reading lights

2 x Concealed LED-lights

2 x Wardrobes

4 x Storage-areas in various sizes

1 x SS porthole

1 x Oceanair curtain

HEADS:

1 Owner’s cabin head, 1 shared day head

Interior design in finest selected teak, 8 layers of varnish, mosaic on walls top in Corian and solid teak floor

1 x Jabsco designer toilet, 24v, with macerator pump

1 x SS holding tank with 2-way valve [on-deck pump-out or ocean pump-out]

1 x Lavatory vessel by Philippe Starck

1 x Lavatory faucet by Vola design/Arne Jacobsen

1 x Shower mixer/volume control by Vola design/Arne Jacobsen

1 x 24v Jabsco shower water pump-out with 2-way valve [on-deck pump-out or ocean pump-out]

1 x 110v outlet

1 x Heat outlet

3 x LED spotlights

1 x Mirror

1 x Twin upper bathroom locker with mirror

1 x Twin lower bathroom locker in teak

1 x 220v towel warmer in polished chrome

1 x Corian floor in shower-area

1 x Toilet paper-holder by Vola design/Arne Jacobsen

4 x Towel hooks by Vola1 x SS + Glass custom made shower enclosure

TENDER:

Williams Jet Tender- Turbo Jet 325
